STANDARD DUTY BRIDGE (SDB) GANTRY KIT WITH CABLE TRACK
Compatible with the candcnc.com Bladerunner AIO 620-4
NO MOTORS OR ELECTRONICS INCLUDED
Pricing:

SDB4X4...............$3195
SDB5X5...............$3295
SDB4X8...............$3395
SDB5X10.............$3495

NOTE:
CUSTOMER MUST SUPPLY THE 1/2" X 3" COLD ROLLED STEEL FOR THE SIDE RAILS.
Precision Plasma LLC - all rights reserved 2014
OPTIONS:
1-1/4HP ROUTER MOUNT +$100
MACHINE TORCH MOUNT UPGRADE +$150
MAGNETIC MACHINE TORCH BREAKAWAY +$300
ALUMINUM BELT REDUCTION UNITS (3) +$500
OPTIONAL ALUMINUM BELT REDUCTION UNITS AVAILABLE FOR +$500 FOR A SET
OF 3. RECOMMENDED IF CUTTING AT SPEEDS LESS THAN 15 IPM. 2:1 REDUCTION
FOR USE WITH 300 IN-OZ MOTORS AND 1.5:1 FOR USE WITH 620 IN-OZ MOTORS.
MOTOR CONFIGURATIONS:

DIRECT DRIVE WITH 620 IN-OZ MOTORS.......RESOLUTION .001"
FOR CUTTING SPEEDS ABOVE 15IPM
2:1 BELT REDUCTION UNITS WITH 300 IN-OZ MOTORS......RESOLUTION .0005"
FOR MAXIMIZING RESOLUTION
1.5:1 BELT REDUCTION UNITS WITH 620 IN-OZ MOTORS.....RESOLUTION .00075"
FOR MAXIMIZING TORQUE
Pricing:

SD4X4...............$2895
SD5X5...............$2995
SD4X8...............$3095
SD5X10.............$3195

Includes:

Assembled gantry
Cable track with support pans for both axis
Gear rack for both axis (splicing required on 8' and 10')
Hardware, (4) bumpers, (8) 2x3 tubing caps, 3M tape
Floating hand torch mount
Weld in slat supports (3)
Includes:

Assembled gantry
Cable track with support pans for both axis
Gear rack for both axis (splicing required on 8' and 10')
Hardware, (4) bumpers, (4) 2x3 tubing caps, 3M tape
Floating hand torch mount
Weld in slat supports (3)
The Standard Duty gantry kit was designed for plasma cutting thin sheetmetal up to 3/4" thick plate.
(minimum cutting speed of 15 ipm direct drive due to the low speed resonance of stepper motors) It also is
a dual purpose machine and can handle a Porter Cable 1-1/4hp compact router. The only difference
between the Light Duty and Standard Duty is the gear rack. The Light Duty has 1/4" and the Standard Duty
has 1/2". The Standard Duty is also available in a 5X10 version since the 1/2" gear rack is easily spliced to
allow for longer lengths.
The Standard Duty Bridge gantry (SDB) is the same as the Standard Duty except the side assemblies
are taller. This allows the side rails of the table to be lower than the bed to allow for loading the
table from the side. This is a great feature for 4X8 and 5X10 tables.
NOTE:
CUSTOMER MUST SUPPLY THE 3/8" X 3" COLD ROLLED STEEL FOR THE SIDE RAILS.
